Joint
- 33kV Mild Steel, Epoxy Coated, Ground Mounted 6+1 Way Link Box
- 33kV Mild Steel, Epoxy Coated, Wall Mounted 3+1 Way Link Box
- 11kV Mild Steel, Epoxy Coated, Ground Mounted 6+1 Way Link Box
- 11kV Mild Steel, Epoxy Coated, Wall Mounted 3+1 Way Link Box
- Marshalling Box 3 Way, 100 Connections Per Way
- Composite Cable Tray
- Reusable Flexiboot
Conductor Size = 70sqmm to 240sqmm
Suitable for 11kV and 22kV
- Scotchcast Resin Pressure Method 61 Series
Conductor Size = 50sqmm to 300sqmm - Scotchcast 88-NA Low Voltage Splicing Kit
Conductor Size = 1.5sqmm to 95sqmm
Joint
- 11kV, QS1000 Straight Through Joint, 1-Core XLPE,
Conductor Size = 70sqmm to 500sqmm - 11kV, QS1000 Straight Through Joint, 3-Core XLPE,
Conductor Size = 95sqmm to 300sqmm - 11kV, QS1000, Transition Joint, 3-Core, PiLC to XLPE,
Conductor Size = 70sqmm to 300sqmm - 11kV, Scotchcast Straight Through Tape Joint and Cross Bond Joint, 1-Core XLPE,
Conductor Size = 500sqmm - 11kV, Scotchcast Straight Through Tape Joint, 3-Core XLPE U/G
Conductor Size = 70sqmm to 300sqmm - 11kV, Scotchcast Straight Through Joint, 3 x 1-Core, XLPE ABC
Conductor Size = 50sqmm to 240sqmm
Terminations
- 11kV, QT II Indoor Termination, 1-Core XLPE,
Conductor Size = 70sqmm to 630sqmm - 11kV, QT II Outdoor Termination, 1-Core XLPE,
Conductor Size = 70sqmm to 630sqmm - 11kV, QT II Indoor Termination, 3-Core XLPE,
Conductor Size = 70sqmm to 300sqmm - 11kV, QT II Outdoor Termination, 3-Core XLPE,
Conductor Size = 70sqmm to 300sqmm
Joints
- 33kV, QS200, Straight Through Joint, 1-Core XLPE
Conductor Size = 50sqmm to 630sqmm - 33kV, QS200, Cross Bond Joint, 1-Core XLPE
Conductor Size = 50sqmm to 630sqmm - 33kV, Scotchcast Tape Compound Joint
Straight Through and Cross Bond Joint,
1-Core, XLPE
Conductor Size = 630sqmm - 33kV, Scotchcast Tape Joint, 1-Core, XLPE
Conductor Size = 120sqmm to 630sqmm - 33kV, Scotchcast Tape Joint, 3-Core, XLPE
Conductor Size = 70sqmm to 300sqmm - 33kV, Scotchcast ABC Straight Through Joint, 3 x 1-Core, XLPE
Conductor Size = 150sqmm to 250sqmm - 33kV, Scotchcast Pilot Cable Joint 37-pair
Conductor Size = 0.6sqmm to 1.29sqmm
Terminations
- 33kV, QT II Indoor Termination, 1-Core XLPE,
Conductor Size = 70sqmm to 630sqmm - 33kV, QT II Outdoor Termination, 1-Core XLPE,
Conductor Size = 70sqmm to 630sqmm - 33kV, QT II Indoor Termination, 3-Core XLPE,
Conductor Size = 70sqmm to 300sqmm - 33kV, QT II Indoor Termination, 3-Core XLPE,
Conductor Size = 70sqmm to 300sqmm
- Scotchcast E4 Resin Pump Gun
- P-1B Injection Valve
- #P-5B Nozzle
- Bitumen Insulating Compound (20kg)
- Polyurethane Resin (420gram)
- Scotch 23, Self-Fusing Rubber Tape, 19mm x 9.1mtr
- Scotch 23, Self-Fusing Rubber Tape, 38mm x 9.1mtr
- 2228 Scotch Rubber Mastic, 50.8mm x 3.1mtr
- Vinyl 1710 Electrical Insulating Tape, 18mm x 10mtr
- Vinyl 1710 Electrical Insulating Tape, 38mm x 10mtr
- Scotch 13, Semi-Conductor Tape, 19mm x 4.5mtr
- Scotch 2220, Stress Tape, 19mm x 1.5mtr
- 934, Filament Restriction, 24mm x 20mtr
- IE77, Transparent PVC Tape, 50mm x 20mtr
- Scotch 24, Electrical Shielding Tape, 25mm x 4.5mtr
- P3F Spacer, 50mm x 20mtr
- Temflex Tape (Red, Yellow, Blue, Green), 18mm x 5mtr
Joint
- Pre-molded Straight Through Joint, 33kV, 1-Core, XLPE
Conductor Size = 500sqmm to 630sqmm - Pre-molded Cross Bond Joint, 33kV, 1-Core, XLPE
Conductor Size = 500sqmm to 630sqmm
